General information
BrandVolvo
Model 960
Generation 960 (964)
Modification (Engine) 2.5 i 24V (170 Hp)
Start of production September, 1994 year
End of production December, 1996 year
Powertrain Architecture Internal Combustion engine
Body typeSedan
Seats 5
Doors 4
Performance specs
Fuel consumption (economy) - combined 10.5 l/100 km 22.4 US mpg26.9 UK mpg9.52 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h9.7 sec
Acceleration 0 - 62 mph9.7 sec
Acceleration 0 - 60 mph 9.2 sec
Maximum speed 210 km/h 130.49 mph
Weight-to-power ratio 9.4 kg/Hp, 106.3 Hp/tonne
Weight-to-torque ratio 7 kg/Nm, 143.8 Nm/tonne
Engine specs
Power 170 Hp @ 5700 rpm.
Power per litre 68.7 Hp/l
Torque 230 Nm @ 4400 rpm. 169.64 lb.-ft. @ 4400 rpm.
Engine location Front, Longitudinal
Engine Model/Code B6254S
Engine displacement 2473 cm3 150.91 cu. in.
Number of cylinders 6
Position of cylinders Inline
Cylinder Bore 81 mm 3.19 in.
Piston Stroke 80 mm 3.15 in.
Compression ratio 10.5
Number of valves per cylinder 4
Fuel System Multi-point indirect injection
Engine aspiration Naturally aspirated engine
Valvetrain DOHC
Engine oil capacity 5.8 l 6.13 US qt | 5.1 UK qt
Oil viscosity No Data
Engine oil specification
Coolant 10.7 l 11.31 US qt | 9.41 UK qt
Space, Volume and weights
Kerb Weight 1600 kg 3527.4 lbs.
Max. weight 1960 kg 4321.06 lbs.
Max load 360 kg 793.66 lbs.
Trunk (boot) space - minimum 491 l 17.34 cu. ft.
Fuel tank capacity 80 l 21.13 US gal | 17.6 UK gal
Dimensions
Length 4871 mm 191.77 in.
Width 1750 mm 68.9 in.
Height 1411 mm 55.55 in.
Wheelbase 2770 mm 109.06 in.
Front track 1502 mm 59.13 in.
Rear (Back) track 1502 mm 59.13 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the rear wheels of the vehicle.
Drive wheel Rear wheel drive
Number of Gears (manual transmission) 5
Front suspension Wishbone
Rear suspension Helical spring
Front brakesVentilated discs
Rear brakesDisc
Assisting systemsABS (Anti-lock braking system)
Power steering Hydraulic Steering
Tires size 195/65 R15 V
Wheel rims size15
