General information
BrandVolkswagen
Model Touran
Generation Touran I (facelift 2006)
Modification (Engine) 1.4 TSI (140 Hp)
Start of production 2009 year
End of production 2010 year
Powertrain Architecture Internal Combustion engine
Body typeMinivan
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) - urban 9.5 l/100 km 24.76 US mpg29.73 UK mpg10.53 km/l
Fuel consumption (economy) - extra urban 6.2 l/100 km 37.94 US mpg45.56 UK mpg16.13 km/l
Fuel consumption (economy) - combined 7.4 l/100 km 31.79 US mpg38.17 UK mpg13.51 km/l
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h9.8 sec
Acceleration 0 - 62 mph9.8 sec
Acceleration 0 - 60 mph 9.3 sec
Maximum speed 200 km/h 124.27 mph
Weight-to-power ratio 10.2 kg/Hp, 98.4 Hp/tonne
Weight-to-torque ratio 6.5 kg/Nm, 154.6 Nm/tonne
Engine specs
Power 140 Hp @ 5600 rpm.
Power per litre 100.7 Hp/l
Torque 220 Nm @ 1500-4000 rpm. 162.26 lb.-ft. @ 1500-4000 rpm.
Engine location Front, Transverse
Engine Model/Code CAVC
Engine displacement 1390 cm3 84.82 cu. in.
Number of cylinders 4
Position of cylinders Inline
Cylinder Bore 76.5 mm 3.01 in.
Piston Stroke 75.6 mm 2.98 in.
Number of valves per cylinder 4
Fuel System Direct injection
Engine aspiration Turbocharging / Mechanical supercharging (Compressor), Intercooler
Valvetrain DOHC
Engine oil capacity 3.6 l 3.8 US qt | 3.17 UK qt
Oil viscosity No Data
Engine oil specification
Space, Volume and weights
Kerb Weight 1423 kg 3137.18 lbs.
Max. weight 2090 kg 4607.66 lbs.
Max load 667 kg 1470.48 lbs.
Trunk (boot) space - minimum 667 l 23.55 cu. ft.
Trunk (boot) space - maximum 1989 l 70.24 cu. ft.
Fuel tank capacity 60 l 15.85 US gal | 13.2 UK gal
Dimensions
Length 4391 mm 172.87 in.
Width 1794 mm 70.63 in.
Height 1652 mm 65.04 in.
Wheelbase 2678 mm 105.43 in.
Front track 1539 mm 60.59 in.
Rear (Back) track 1521 mm 59.88 in.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of Gears (manual transmission) 6
Front suspension Coil spring
Rear suspension Spring Strut
Front brakesVentilated discs
Rear brakesDisc
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Tires size 205/55 R16
Wheel rims size16
