General information |
Brand | Volkswagen |
Model | Sharan |
Generation | Sharan I (facelift 2004) |
Modification (Engine) | 1.8 T (150 Hp) |
Start of production | 2004 year |
End of production | 2010 year |
Powertrain Architecture | Internal Combustion engine |
Body type | Minivan, MPV |
Seats | 7 |
Doors | 5 |
Performance specs |
---|
Fuel consumption (economy) - urban (NEDC) |
13 l/100 km
18.09 US mpg21.73 UK mpg7.69 km/l |
Fuel consumption (economy) - extra urban (NEDC) |
7.4 l/100 km
31.79 US mpg38.17 UK mpg13.51 km/l |
Fuel consumption (economy) - combined (NEDC) |
9.4 l/100 km
25.02 US mpg30.05 UK mpg10.64 km/l |
CO2 emissions (NEDC) | 225 g/km |
Fuel Type | Petrol (Gasoline) |
Acceleration 0 - 100 km/h | 10.9 sec |
Acceleration 0 - 62 mph | 10.9 sec |
Acceleration 0 - 60 mph | 10.4 sec |
Maximum speed |
199 km/h
123.65 mph |
Emission standard | Euro 4 |
Weight-to-power ratio | 11.3 kg/Hp, 88.4 Hp/tonne |
Weight-to-torque ratio | 7.7 kg/Nm, 129.6 Nm/tonne |
Engine specs |
---|
Power | 150 Hp @ 5800 rpm. |
Power per litre | 84.2 Hp/l |
Torque |
220 Nm @ 1800-4300 rpm.
162.26 lb.-ft. @ 1800-4300 rpm. |
Engine location | Front, Transverse |
Engine Model/Code | AWC |
Engine displacement |
1781 cm3
108.68 cu. in. |
Number of cylinders | 4 |
Position of cylinders | Inline |
Cylinder Bore |
81 mm
3.19 in. |
Piston Stroke |
86.4 mm
3.4 in. |
Compression ratio | 9.5 |
Number of valves per cylinder | 5 |
Fuel System | Multi-point indirect injection |
Engine aspiration | Turbocharger, Intercooler |
Valvetrain | DOHC |
Engine oil capacity |
4 l
4.23 US qt | 3.52 UK qt |
Oil viscosity | No Data |
Engine oil specification |
Coolant |
6.3 l
6.66 US qt | 5.54 UK qt |
|
---|
Space, Volume and weights |
---|
Kerb Weight |
1697 kg
3741.24 lbs. |
Max. weight |
2450 kg
5401.33 lbs. |
Max load |
753 kg
1660.08 lbs. |
Trunk (boot) space - minimum |
256 l
9.04 cu. ft. |
Trunk (boot) space - maximum |
2610 l
92.17 cu. ft. |
Fuel tank capacity |
70 l
18.49 US gal | 15.4 UK gal |
Max. roof load |
75 kg
165.35 lbs. |
Permitted trailer load with brakes (12%) |
1900 kg
4188.78 lbs. |
Permitted trailer load without brakes |
700 kg
1543.24 lbs. |
Permitted towbar download |
85 kg
187.39 lbs. |
Dimensions |
---|
Length |
4634 mm
182.44 in. |
Width |
1810 mm
71.26 in. |
Width including mirrors |
2142 mm
84.33 in. |
Height |
1730 mm
68.11 in. |
Wheelbase |
2835 mm
111.61 in. |
Front track |
1530 mm
60.24 in. |
Rear (Back) track |
1524 mm
60 in. |
Minimum turning circle (turning diameter) |
10.9 m
35.76 ft. |
Approach angle | 13.6° |
Departure angle | 14.6° |
Ramp-over (brakeover) angle | 13° |
Drivetrain, brakes and suspension specs |
---|
Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
Drive wheel | Front wheel drive |
Number of Gears (manual transmission) | 6 |
Front suspension | Independent type McPherson, Transverse stabilizer |
Rear suspension | Helical spring, Transverse stabilizer, Trailing arm |
Front brakes | Ventilated discs |
Rear brakes | Disc |
Assisting systems | ABS (Anti-lock braking system) |
Steering type | Steering rack and pinion |
Power steering | Hydraulic Steering |
Tires size | 215/55 R16 |
Wheel rims size | 7J x 16 |
|
