| General information |
|---|
| Brand | Toyota |
|---|
| Model | Avensis |
|---|
| Generation | Avensis II Wagon |
|---|
| Modification (Engine) | 1.6 VVT-i (110 Hp) |
|---|
| Start of production | 2003 year |
|---|
| End of production | 2009 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Station wagon (estate) |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
9.4 l/100 km
25.02 US mpg30.05 UK mpg10.64 km/l |
| Fuel consumption (economy) - extra urban |
5.8 l/100 km
40.55 US mpg48.7 UK mpg17.24 km/l |
| Fuel consumption (economy) - combined |
7.2 l/100 km
32.67 US mpg39.23 UK mpg13.89 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 12.2 sec |
|---|
| Acceleration 0 - 62 mph | 12.2 sec |
|---|
| Acceleration 0 - 60 mph | 11.6 sec |
|---|
| Maximum speed |
185 km/h
114.95 mph |
| Weight-to-power ratio | 11.8 kg/Hp, 84.9 Hp/tonne |
|---|
| Weight-to-torque ratio | 8.6 kg/Nm, 115.8 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 110 Hp @ 6000 rpm. |
|---|
| Power per litre | 68.8 Hp/l |
|---|
| Torque |
150 Nm @ 4800 rpm.
110.63 lb.-ft. @ 4800 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | 3ZZ-FE |
|---|
| Engine displacement |
1598 cm3
97.52 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
79 mm
3.11 in. |
| Piston Stroke |
81.5 mm
3.21 in. |
| Compression ratio | 10.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
3.7 l
3.91 US qt | 3.26 UK qt |
| Oil viscosity | No Data |
| Coolant |
5.8 l
6.13 US qt | 5.1 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1295 kg
2854.99 lbs. |
| Max. weight |
1820 kg
4012.41 lbs. |
| Max load |
525 kg
1157.43 lbs. |
| Trunk (boot) space - minimum |
520 l
18.36 cu. ft. |
| Trunk (boot) space - maximum |
1500 l
52.97 cu. ft. |
| Fuel tank capacity |
60 l
15.85 US gal | 13.2 UK gal |
| Dimensions |
|---|
| Length |
4700 mm
185.04 in. |
| Width |
1760 mm
69.29 in. |
| Height |
1525 mm
60.04 in. |
| Wheelbase |
2700 mm
106.3 in. |
| Front track |
1505 mm
59.25 in. |
| Rear (Back) track |
1505 mm
59.25 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Coil spring |
|---|
| Rear suspension | Helical spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 205/55 R16 |
|
|---|
