| General information |
|---|
| Brand | Toyota |
|---|
| Model | Avensis |
|---|
| Generation | Avensis Hatch (T22) |
|---|
| Modification (Engine) | 1.6 (101 Hp) |
|---|
| Start of production | 1997 year |
|---|
| End of production | 2003 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Hatchback |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
9.7 l/100 km
24.25 US mpg29.12 UK mpg10.31 km/l |
| Fuel consumption (economy) - extra urban |
6 l/100 km
39.2 US mpg47.08 UK mpg16.67 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 12.1 sec |
|---|
| Acceleration 0 - 62 mph | 12.1 sec |
|---|
| Acceleration 0 - 60 mph | 11.5 sec |
|---|
| Maximum speed |
190 km/h
118.06 mph |
| Weight-to-power ratio | 12.3 kg/Hp, 81.1 Hp/tonne |
|---|
| Weight-to-torque ratio | 9.2 kg/Nm, 109.2 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 101 Hp @ 5800 rpm. |
|---|
| Power per litre | 63.6 Hp/l |
|---|
| Torque |
136 Nm @ 4400 rpm.
100.31 lb.-ft. @ 4400 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | 3ZZ-FE |
|---|
| Engine displacement |
1587 cm3
96.84 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
81 mm
3.19 in. |
| Piston Stroke |
77 mm
3.03 in. |
| Compression ratio | 9.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
3.7 l
3.91 US qt | 3.26 UK qt |
| Oil viscosity | No Data |
| Coolant |
7.4-8.1 l
7.82 - 8.56 US qt | 6.51 - 7.13 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1245 kg
2744.76 lbs. |
| Max. weight |
1730 kg
3814 lbs. |
| Max load |
485 kg
1069.24 lbs. |
| Trunk (boot) space - minimum |
510 l
18.01 cu. ft. |
| Fuel tank capacity |
60 l
15.85 US gal | 13.2 UK gal |
| Dimensions |
|---|
| Length |
4490 mm
176.77 in. |
| Width |
1710 mm
67.32 in. |
| Height |
1425 mm
56.1 in. |
| Wheelbase |
2630 mm
103.54 in. |
| Front track |
1480 mm
58.27 in. |
| Rear (Back) track |
1450 mm
57.09 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Spring Strut |
|---|
| Rear suspension | Helical spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | 185/65 R14 |
|
|---|
