| General information |
|---|
| Brand | Toyota |
|---|
| Model | Alphard |
|---|
| Generation | Alphard III (facelift 2017) |
|---|
| Modification (Engine) | 3.5 V6 (300 Hp) Automatic |
|---|
| Start of production | 2017 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan |
|---|
| Seats | 7 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
14.3 l/100 km
16.45 US mpg19.75 UK mpg6.99 km/l |
| Fuel consumption (economy) - extra urban |
8.3 l/100 km
28.34 US mpg34.03 UK mpg12.05 km/l |
| Fuel consumption (economy) - combined |
10.5 l/100 km
22.4 US mpg26.9 UK mpg9.52 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 8.3 sec |
|---|
| Acceleration 0 - 62 mph | 8.3 sec |
|---|
| Acceleration 0 - 60 mph | 7.9 sec |
|---|
| Maximum speed |
200 km/h
124.27 mph |
| Emission standard | Euro 5 |
|---|
| Weight-to-power ratio | 7.1 kg/Hp, 141.2 Hp/tonne |
|---|
| Weight-to-torque ratio | 5.9 kg/Nm, 169.9 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 300 Hp @ 6600 rpm. |
|---|
| Power per litre | 86.8 Hp/l |
|---|
| Torque |
361 Nm @ 4600-4700 rpm.
266.26 lb.-ft. @ 4600-4700 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | 2GR-FKS |
|---|
| Engine displacement |
3456 cm3
210.9 cu. in. |
| Number of cylinders | 6 |
|---|
| Position of cylinders | V-engine |
|---|
| Cylinder Bore |
94 mm
3.7 in. |
| Piston Stroke |
83 mm
3.27 in. |
| Compression ratio | 10 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | Dual VVT-i |
|---|
| Engine oil capacity |
5.4 l
5.71 US qt | 4.75 UK qt |
| Oil viscosity | No Data |
| Coolant |
10.7 l
11.31 US qt | 9.41 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
2125 kg
4684.82 lbs. |
| Max. weight |
2675 kg
5897.37 lbs. |
| Max load |
550 kg
1212.54 lbs. |
| Fuel tank capacity |
65 l
17.17 US gal | 14.3 UK gal |
| Dimensions |
|---|
| Length |
4945 mm
194.69 in. |
| Width |
1850 mm
72.83 in. |
| Height |
1945 mm
76.57 in. |
| Wheelbase |
3000 mm
118.11 in. |
| Ride height (ground clearance) |
160 mm
6.3 in. |
| Minimum turning circle (turning diameter) |
11.4 m
37.4 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (automatic transmission) | 8 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Independent, spring multi-link with stabilizer |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Ventilated discs |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 225/60 R17; 235/50 R18 |
| Wheel rims size | 17; 18 |
|---|
|
|---|
