| General information |
|---|
| Brand | Suzuki |
|---|
| Model | Ignis |
|---|
| Generation | Ignis II |
|---|
| Modification (Engine) | 1.2 DualJet (90 Hp) |
|---|
| Start of production | 2016 year |
|---|
| End of production | December, 2019 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | SUV |
|---|
| Seats | 4 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
5.5 l/100 km
42.77 US mpg51.36 UK mpg18.18 km/l |
| Fuel consumption (economy) - extra urban |
4.1 l/100 km
57.37 US mpg68.9 UK mpg24.39 km/l |
| Fuel consumption (economy) - combined |
4.6 l/100 km
51.13 US mpg61.41 UK mpg21.74 km/l |
| CO2 emissions | 104 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 12.2 sec |
|---|
| Acceleration 0 - 62 mph | 12.2 sec |
|---|
| Acceleration 0 - 60 mph | 11.6 sec |
|---|
| Maximum speed |
170 km/h
105.63 mph |
| Emission standard | Euro 6 |
|---|
| Weight-to-power ratio | 9 kg/Hp, 111.1 Hp/tonne |
|---|
| Weight-to-torque ratio | 6.8 kg/Nm, 148.1 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 90 Hp @ 6000 rpm. |
|---|
| Power per litre | 72.5 Hp/l |
|---|
| Torque |
120 Nm @ 4400 rpm.
88.51 lb.-ft. @ 4400 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | K12C |
|---|
| Engine displacement |
1242 cm3
75.79 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
73 mm
2.87 in. |
| Piston Stroke |
74.2 mm
2.92 in. |
| Compression ratio | 12.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Engine oil capacity |
3.3 l
3.49 US qt | 2.9 UK qt |
| Oil viscosity | No Data |
| Coolant |
4 l
4.23 US qt | 3.52 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
810-855 kg
1785.74 - 1884.95 lbs. |
| Max. weight |
1330 kg
2932.15 lbs. |
| Max load |
475-520 kg
1047.2 - 1146.4 lbs. |
| Trunk (boot) space - minimum |
260 l
9.18 cu. ft. |
| Trunk (boot) space - maximum |
1100 l
38.85 cu. ft. |
| Fuel tank capacity |
32 l
8.45 US gal | 7.04 UK gal |
| Permitted trailer load with brakes (12%) |
1000 kg
2204.62 lbs. |
| Permitted trailer load without brakes |
400 kg
881.85 lbs. |
| Permitted towbar download |
50 kg
110.23 lbs. |
| Dimensions |
|---|
| Length |
3700 mm
145.67 in. |
| Width |
1660-1690 mm
65.35 - 66.54 in. |
| Height |
1595 mm
62.8 in. |
| Wheelbase |
2435 mm
95.87 in. |
| Front track |
1460 mm
57.48 in. |
| Rear (Back) track |
1470 mm
57.87 in. |
| Ride height (ground clearance) |
180 mm
7.09 in. |
| Minimum turning circle (turning diameter) |
9.4 m
30.84 ft. |
| Approach angle | 20° |
|---|
| Departure angle | 38.8° |
|---|
| Ramp-over (brakeover) angle | 18° |
|---|
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent type McPherson |
|---|
| Rear suspension | Semi-independent, coil spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 175/65 R15; 175/60 R16 |
| Wheel rims size | 15; 16 |
|---|
|
|---|
