| General information |
|---|
| Brand | Skoda |
|---|
| Model | Fabia |
|---|
| Generation | Fabia II Combi (facelift 2010) |
|---|
| Modification (Engine) | 1.2 (60 Hp) |
|---|
| Start of production | November, 2011 year |
|---|
| End of production | 2014 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Station wagon (estate) |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
7.3 l/100 km
32.22 US mpg38.7 UK mpg13.7 km/l |
| Fuel consumption (economy) - extra urban |
4.5 l/100 km
52.27 US mpg62.77 UK mpg22.22 km/l |
| Fuel consumption (economy) - combined |
5.5 l/100 km
42.77 US mpg51.36 UK mpg18.18 km/l |
| CO2 emissions | 128 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 16.7 sec |
|---|
| Acceleration 0 - 62 mph | 16.7 sec |
|---|
| Acceleration 0 - 60 mph | 15.9 sec |
|---|
| Maximum speed |
156 km/h
96.93 mph |
| Emission standard | Euro 5 |
|---|
| Weight-to-power ratio | 18.6 kg/Hp, 53.8 Hp/tonne |
|---|
| Weight-to-torque ratio | 10.3 kg/Nm, 96.9 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 60 Hp @ 5200 rpm. |
|---|
| Power per litre | 50.1 Hp/l |
|---|
| Torque |
108 Nm @ 3000 rpm.
79.66 lb.-ft. @ 3000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | CGPB |
|---|
| Engine displacement |
1198 cm3
73.11 cu. in. |
| Number of cylinders | 3 |
|---|
| Position of cylinders | Inline |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Engine oil capacity |
2.8 l
2.96 US qt | 2.46 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
5.5 l
5.81 US qt | 4.84 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1115 kg
2458.15 lbs. |
| Max. weight |
1570 kg
3461.26 lbs. |
| Max load |
455 kg
1003.1 lbs. |
| Fuel tank capacity |
45 l
11.89 US gal | 9.9 UK gal |
| Dimensions |
|---|
| Length |
4247 mm
167.2 in. |
| Width |
1642 mm
64.65 in. |
| Height |
1498 mm
58.98 in. |
| Wheelbase |
2465 mm
97.05 in. |
| Front track |
1433 mm
56.42 in. |
| Rear (Back) track |
1426 mm
56.14 in. |
| Minimum turning circle (turning diameter) |
10 m
32.81 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Independent, spring multi-link with stabilizer |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 165/70 R14; 185/60 R14; 195/55 R15 |
| Wheel rims size | 5.0J x 14; 6.0J x 14; 6.0J x 15 |
|---|
|
|---|
