General information
BrandSeat
Model Leon
Generation Leon III ST (facelift 2016)
Modification (Engine) 1.0 EcoTSI (115 Hp) ECOMOTIVE
Start of production 2018 year
End of production 2020 year
Powertrain Architecture Internal Combustion engine
Body typeStation wagon (estate)
Seats 5
Doors 5
Performance specs
Fuel consumption (economy) - urban 5.5 l/100 km 42.77 US mpg51.36 UK mpg18.18 km/l
Fuel consumption (economy) - extra urban 4.3 l/100 km 54.7 US mpg65.69 UK mpg23.26 km/l
Fuel consumption (economy) - combined 4.8 l/100 km 49 US mpg58.85 UK mpg20.83 km/l
CO2 emissions108 g/km
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h10.1 sec
Acceleration 0 - 62 mph10.1 sec
Acceleration 0 - 60 mph 9.6 sec
Maximum speed 200 km/h 124.27 mph
Emission standard Euro 6 AG
Weight-to-power ratio 10.1 kg/Hp, 98.5 Hp/tonne
Weight-to-torque ratio 5.8 kg/Nm, 171.4 Nm/tonne
Engine specs
Power 115 Hp @ 5000-5500 rpm.
Power per litre 115.1 Hp/l
Torque 200 Nm @ 2000-3500 rpm. 147.51 lb.-ft. @ 2000-3500 rpm.
Engine location Front, Transverse
Engine Model/Code DKRA, DKRF
Engine displacement 999 cm3 60.96 cu. in.
Number of cylinders 3
Position of cylinders Inline
Cylinder Bore 74.5 mm 2.93 in.
Piston Stroke 76.4 mm 3.01 in.
Compression ratio 10.5
Number of valves per cylinder 4
Fuel System Direct injection
Engine aspiration Turbocharger
Engine oil capacity 4 l 4.23 US qt | 3.52 UK qt
Oil viscosity No Data
Engine oil specification
Coolant 8 l 8.45 US qt | 7.04 UK qt
Space, Volume and weights
Kerb Weight 1167 kg 2572.79 lbs.
Max. weight 1780 kg 3924.23 lbs.
Max load 613 kg 1351.43 lbs.
Trunk (boot) space - minimum 587 l 20.73 cu. ft.
Trunk (boot) space - maximum 1470 l 51.91 cu. ft.
Fuel tank capacity 55 l 14.53 US gal | 12.1 UK gal
Permitted trailer load without brakes 620 kg 1366.87 lbs.
Dimensions
Length 4549 mm 179.09 in.
Width 1816 mm 71.5 in.
Width including mirrors 1975 mm 77.76 in.
Height 1454 mm 57.24 in.
Wheelbase 2636 mm 103.78 in.
Front track 1549 mm 60.98 in.
Rear (Back) track 1520 mm 59.84 in.
Front overhang 861 mm 33.9 in.
Rear overhang 1052 mm 41.42 in.
Minimum turning circle (turning diameter) 10.3 m 33.79 ft.
Drivetrain, brakes and suspension specs
Drivetrain Architecture The Internal combustion engine (ICE) drives the front wheels of the vehicle.
Drive wheel Front wheel drive
Number of Gears (manual transmission) 6
Front suspension Independent type McPherson
Rear suspension Semi-independent, coil spring
Front brakesVentilated discs, 276 mm
Rear brakesDisc, 253 mm
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 205/55 R16
Wheel rims size6J x 15; 6.5J x 16
