| General information |
|---|
| Brand | Seat |
|---|
| Model | Ibiza |
|---|
| Generation | Ibiza V |
|---|
| Modification (Engine) | 1.0 EcoTSI (95 Hp) |
|---|
| Start of production | 2019 year |
|---|
| End of production | June, 2021 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Hatchback |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Combined fuel consumption (WLTP) |
5.4-5.6 l/100 km
43.56 - 42 US mpg52.31 - 50.44 UK mpg18.52 - 17.86 km/l |
| CO2 emissions (WLTP) | 121-126 g/km |
|---|
| Fuel consumption (economy) - urban |
5.6 l/100 km
42 US mpg50.44 UK mpg17.86 km/l |
| Fuel consumption (economy) - extra urban |
4.0 l/100 km
58.8 US mpg70.62 UK mpg25 km/l |
| Fuel consumption (economy) - combined |
4.6 l/100 km
51.13 US mpg61.41 UK mpg21.74 km/l |
| CO2 emissions | 104 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 10.9 sec |
|---|
| Acceleration 0 - 62 mph | 10.9 sec |
|---|
| Acceleration 0 - 60 mph | 10.4 sec |
|---|
| Maximum speed |
182 km/h
113.09 mph |
| Emission standard | Euro 6 DG |
|---|
| Weight-to-power ratio | 11.1 kg/Hp, 89.7 Hp/tonne |
|---|
| Weight-to-torque ratio | 6.1 kg/Nm, 165.3 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 95 Hp @ 5000-5500 rpm. |
|---|
| Power per litre | 95.1 Hp/l |
|---|
| Torque |
175 Nm @ 1500-3500 rpm.
129.07 lb.-ft. @ 1500-3500 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | DKLA |
|---|
| Engine displacement |
999 cm3
60.96 cu. in. |
| Number of cylinders | 3 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
74.5 mm
2.93 in. |
| Piston Stroke |
76.4 mm
3.01 in. |
| Compression ratio | 10.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Turbocharger |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
4 l
4.23 US qt | 3.52 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
10 l
10.57 US qt | 8.8 UK qt |
| Engine systems | Start & Stop SystemParticulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1059 kg
2334.7 lbs. |
| Max. weight |
1640 kg
3615.58 lbs. |
| Max load |
581 kg
1280.89 lbs. |
| Trunk (boot) space - minimum |
355 l
12.54 cu. ft. |
| Trunk (boot) space - maximum |
1165 l
41.14 cu. ft. |
| Fuel tank capacity |
40 l
10.57 US gal | 8.8 UK gal |
| Max. roof load |
75 kg
165.35 lbs. |
| Permitted trailer load with brakes (8%) |
1100 kg
2425.08 lbs. |
| Permitted trailer load with brakes (12%) |
1000 kg
2204.62 lbs. |
| Permitted trailer load without brakes |
560 kg
1234.59 lbs. |
| Permitted towbar download |
50 kg
110.23 lbs. |
| Dimensions |
|---|
| Length |
4059 mm
159.8 in. |
| Width |
1780 mm
70.08 in. |
| Width including mirrors |
1942 mm
76.46 in. |
| Height |
1444 mm
56.85 in. |
| Wheelbase |
2564 mm
100.94 in. |
| Front track |
1525 mm
60.04 in. |
| Rear (Back) track |
1505 mm
59.25 in. |
| Front overhang |
796 mm
31.34 in. |
| Rear overhang |
699 mm
27.52 in. |
| Minimum turning circle (turning diameter) |
10.6 m
34.78 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Semi-independent, coil spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 185/65 R15; 215/40 R18 |
| Wheel rims size | 5.5J x 15; 7J x 18 |
|---|
|
|---|
