| General information |
|---|
| Brand | Peugeot |
|---|
| Model | Partner |
|---|
| Generation | Partner III Van Long |
|---|
| Modification (Engine) | 1.5 BlueHDi (131 Hp) S&S |
|---|
| Start of production | 2019 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
4.9 l/100 km
48 US mpg57.65 UK mpg20.41 km/l |
| Fuel consumption (economy) - extra urban |
4.1 l/100 km
57.37 US mpg68.9 UK mpg24.39 km/l |
| Fuel consumption (economy) - combined |
4.4 l/100 km
53.46 US mpg64.2 UK mpg22.73 km/l |
| CO2 emissions | 116 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 10.1 sec |
|---|
| Acceleration 0 - 62 mph | 10.1 sec |
|---|
| Acceleration 0 - 60 mph | 9.6 sec |
|---|
| Maximum speed |
185 km/h
114.95 mph |
| Emission standard | Euro 6 |
|---|
| Weight-to-power ratio | 10.9 kg/Hp, 91.6 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.8 kg/Nm, 209.8 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 131 Hp @ 3750 rpm. |
|---|
| Power per litre | 87.4 Hp/l |
|---|
| Torque |
300 Nm @ 1750 rpm.
221.27 lb.-ft. @ 1750 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | YHZ DV5RC |
|---|
| Engine displacement |
1499 cm3
91.47 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
75 mm
2.95 in. |
| Piston Stroke |
84.8 mm
3.34 in. |
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Engine oil capacity |
5.3 l
5.6 US qt | 4.66 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Engine systems | Start & Stop SystemParticulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1430 kg
3152.61 lbs. |
| Max. weight |
2400 kg
5291.09 lbs. |
| Max load |
970 kg
2138.48 lbs. |
| Trunk (boot) space - maximum |
4400 l
155.38 cu. ft. |
| Fuel tank capacity |
50 l
13.21 US gal | 11 UK gal |
| AdBlue tank |
17 l
4.49 US gal | 3.74 UK gal |
| Permitted trailer load with brakes (12%) |
1200 kg
2645.55 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
74 kg
163.14 lbs. |
| Dimensions |
|---|
| Length |
4753 mm
187.13 in. |
| Width |
1848 mm
72.76 in. |
| Width including mirrors |
2107 mm
82.95 in. |
| Height |
1849-1860 mm
72.8 - 73.23 in. |
| Wheelbase |
2975 mm
117.13 in. |
| Front overhang |
892 mm
35.12 in. |
| Rear overhang |
886 mm
34.88 in. |
| Minimum turning circle (turning diameter) |
11.43 m
37.5 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 205/60 R16 |
| Wheel rims size | 16 |
|---|
|
|---|
