| General information |
|---|
| Brand | Peugeot |
|---|
| Model | 405 |
|---|
| Generation | 405 I Break (15E, facelift 1992) |
|---|
| Modification (Engine) | 1.6 (89 Hp) |
|---|
| Start of production | 1992 year |
|---|
| End of production | 1996 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Station wagon (estate) |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - combined |
7.4 l/100 km
31.79 US mpg38.17 UK mpg13.51 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 14.1 sec |
|---|
| Acceleration 0 - 62 mph | 14.1 sec |
|---|
| Acceleration 0 - 60 mph | 13.4 sec |
|---|
| Maximum speed |
173 km/h
107.5 mph |
| Weight-to-power ratio | 12.2 kg/Hp, 81.7 Hp/tonne |
|---|
| Weight-to-torque ratio | 8.1 kg/Nm, 123.9 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 89 Hp @ 5600 rpm. |
|---|
| Power per litre | 56.1 Hp/l |
|---|
| Torque |
135 Nm @ 3000 rpm.
99.57 lb.-ft. @ 3000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | BDY XU5M2Z |
|---|
| Engine displacement |
1587 cm3
96.84 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
78.5 mm
3.09 in. |
| Piston Stroke |
82 mm
3.23 in. |
| Compression ratio | 10 |
|---|
| Number of valves per cylinder | 2 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | OHC |
|---|
| Engine oil capacity |
4.6-4.8 l
4.86 - 5.07 US qt | 4.05 - 4.22 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
6.6 l
6.97 US qt | 5.81 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1090 kg
2403.04 lbs. |
| Max. weight |
1590 kg
3505.35 lbs. |
| Max load |
500 kg
1102.31 lbs. |
| Trunk (boot) space - minimum |
425 l
15.01 cu. ft. |
| Trunk (boot) space - maximum |
744 l
26.27 cu. ft. |
| Fuel tank capacity |
70 l
18.49 US gal | 15.4 UK gal |
| Dimensions |
|---|
| Length |
4398 mm
173.15 in. |
| Width |
1704 mm
67.09 in. |
| Height |
1481 mm
58.31 in. |
| Wheelbase |
2669 mm
105.08 in. |
| Front track |
1450 mm
57.09 in. |
| Rear (Back) track |
1443 mm
56.81 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Wishbone |
|---|
| Rear suspension | Trailing arm |
|---|
| Front brakes | Disc |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | 175/70 R14 |
|
|---|
