| General information |
|---|
| Brand | Mitsubishi |
|---|
| Model | L200 |
|---|
| Generation | L200 V Double Cab |
|---|
| Modification (Engine) | 2.4d (154 Hp) 4WD |
|---|
| Start of production | 2015 year |
|---|
| End of production | 2018 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Pick-up |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
8.2 l/100 km
28.68 US mpg34.45 UK mpg12.2 km/l |
| Fuel consumption (economy) - extra urban |
6.1 l/100 km
38.56 US mpg46.31 UK mpg16.39 km/l |
| Fuel consumption (economy) - combined |
6.9 l/100 km
34.09 US mpg40.94 UK mpg14.49 km/l |
| CO2 emissions | 180 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 12.2 sec |
|---|
| Acceleration 0 - 62 mph | 12.2 sec |
|---|
| Acceleration 0 - 60 mph | 11.6 sec |
|---|
| Maximum speed |
169 km/h
105.01 mph |
| Emission standard | Euro 6b |
|---|
| Weight-to-power ratio | 12 kg/Hp, 83 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.9 kg/Nm, 204.9 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 154 Hp @ 3500 rpm. |
|---|
| Power per litre | 63.1 Hp/l |
|---|
| Torque |
380 Nm @ 1500-2500 rpm.
280.27 lb.-ft. @ 1500-2500 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine displacement |
2442 cm3
149.02 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
86 mm
3.39 in. |
| Piston Stroke |
105.1 mm
4.14 in. |
| Compression ratio | 15.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Valvetrain | DOHC |
|---|
| Engine systems | Particulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1855 kg
4089.57 lbs. |
| Max. weight |
2900 kg
6393.41 lbs. |
| Max load |
1045 kg
2303.83 lbs. |
| Fuel tank capacity |
75 l
19.81 US gal | 16.5 UK gal |
| Permitted trailer load with brakes (12%) |
3500 kg
7716.18 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
140 kg
308.65 lbs. |
| Dimensions |
|---|
| Length |
5205 mm
204.92 in. |
| Width |
1785 mm
70.28 in. |
| Height |
1775 mm
69.88 in. |
| Wheelbase |
3000 mm
118.11 in. |
| Front track |
1520 mm
59.84 in. |
| Rear (Back) track |
1515 mm
59.65 in. |
| Front overhang |
865 mm
34.06 in. |
| Rear overhang |
1340 mm
52.76 in. |
| Ride height (ground clearance) |
200 mm
7.87 in. |
| Approach angle | 30.0° |
|---|
| Departure angle | 25.0° |
|---|
| Ramp-over (brakeover) angle | 23.0° |
|---|
| Drivetrain, brakes and suspension specs |
|---|
| Drive wheel | All wheel drive (4x4) |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Double wishbone |
|---|
| Rear suspension | Dependent suspension of two longitudinal semi-elliptic leaf springs |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 205/80 R16 |
| Wheel rims size | 6J x 16 |
|---|
|
|---|
