| General information |
|---|
| Brand | Maserati |
|---|
| Model | Ghibli |
|---|
| Generation | Ghibli I (AM115) |
|---|
| Modification (Engine) | SS 5.0 V8 (335 Hp) |
|---|
| Start of production | June, 1969 year |
|---|
| End of production | December, 1973 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Coupe, Fastback |
|---|
| Seats | 2 |
|---|
| Doors | 2 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - combined |
15.7-14.7 l/100 km
14.98 - 16 US mpg17.99 - 19.22 UK mpg6.37 - 6.8 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 5.3 sec |
|---|
| Acceleration 0 - 62 mph | 5.3 sec |
|---|
| Acceleration 0 - 60 mph | 5 sec |
|---|
| Maximum speed |
280 km/h
173.98 mph |
| Weight-to-power ratio | 4.9 kg/Hp, 202.9 Hp/tonne |
|---|
| Weight-to-torque ratio | 3.6 kg/Nm, 279.2 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 335 Hp @ 5500 rpm. |
|---|
| Power per litre | 68 Hp/l |
|---|
| Torque |
461 Nm @ 5500 rpm.
340.02 lb.-ft. @ 5500 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine displacement |
4930 cm3
300.85 cu. in. |
| Number of cylinders | 8 |
|---|
| Position of cylinders | V-engine |
|---|
| Cylinder Bore |
93.9 mm
3.7 in. |
| Piston Stroke |
89 mm
3.5 in. |
| Compression ratio | 8.5 |
|---|
| Number of valves per cylinder | 2 |
|---|
| Fuel System | Carburettor |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
13 l
13.74 US qt | 11.44 UK qt |
| Oil viscosity | No Data |
| Coolant |
14 l
14.79 US qt | 12.32 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1651 kg
3639.83 lbs. |
| Max. weight |
1850 kg
4078.55 lbs. |
| Max load |
199 kg
438.72 lbs. |
| Trunk (boot) space - minimum |
680 l
24.01 cu. ft. |
| Fuel tank capacity |
100 l
26.42 US gal | 22 UK gal |
| Dimensions |
|---|
| Length |
4690 mm
184.65 in. |
| Width |
1790 mm
70.47 in. |
| Height |
1160 mm
45.67 in. |
| Wheelbase |
2550 mm
100.39 in. |
| Front track |
1440 mm
56.69 in. |
| Rear (Back) track |
1420 mm
55.91 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent, spring, Torsion |
|---|
| Rear suspension | Helical spring, Torsion |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Ventilated discs |
|---|
| Steering type | Cone worm with recirculation balls |
|---|
| Tires size | 215/70 R15 |
| Wheel rims size | 7.5J x 15 |
|---|
|
|---|
