| General information |
|---|
| Brand | Kia |
|---|
| Model | Sedona |
|---|
| Generation | Sedona III |
|---|
| Modification (Engine) | 3.3 V6 (280 Hp) Automatic |
|---|
| Start of production | 2015 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan |
|---|
| Seats | 7-8 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
13.1 l/100 km
17.96 US mpg21.56 UK mpg7.63 km/l |
| Fuel consumption (economy) - extra urban |
9.8 l/100 km
24 US mpg28.82 UK mpg10.2 km/l |
| Fuel consumption (economy) - combined |
11.8 l/100 km
19.93 US mpg23.94 UK mpg8.47 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 8.2 sec |
|---|
| Acceleration 0 - 62 mph | 8.2 sec |
|---|
| Acceleration 0 - 60 mph | 7.8 sec |
|---|
| Maximum speed |
217 km/h
134.84 mph |
| Weight-to-power ratio | 7.1 kg/Hp, 139.9 Hp/tonne |
|---|
| Weight-to-torque ratio | 6 kg/Nm, 167.9 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 280 Hp @ 6000 rpm. |
|---|
| Power per litre | 83.8 Hp/l |
|---|
| Torque |
336 Nm @ 5200 rpm.
247.82 lb.-ft. @ 5200 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
3342 cm3
203.94 cu. in. |
| Number of cylinders | 6 |
|---|
| Position of cylinders | V-engine |
|---|
| Cylinder Bore |
92 mm
3.62 in. |
| Piston Stroke |
83.8 mm
3.3 in. |
| Compression ratio | 11.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC-CVVT |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
2001-2059 kg
4411.45 - 4539.32 lbs. |
| Max. weight |
2760 kg
6084.76 lbs. |
| Max load |
701-759 kg
1545.44 - 1673.31 lbs. |
| Trunk (boot) space - minimum |
2220 l
78.4 cu. ft. |
| Trunk (boot) space - maximum |
4021 l
142 cu. ft. |
| Fuel tank capacity |
80 l
21.13 US gal | 17.6 UK gal |
| Permitted trailer load with brakes (12%) |
1588 kg
3500.94 lbs. |
| Dimensions |
|---|
| Length |
5116 mm
201.42 in. |
| Width |
1984 mm
78.11 in. |
| Width including mirrors |
2268 mm
89.29 in. |
| Height |
1740 mm
68.5 in. |
| Wheelbase |
3061 mm
120.51 in. |
| Front track |
1740 mm
68.5 in. |
| Rear (Back) track |
1747 mm
68.78 in. |
| Ride height (ground clearance) |
170 mm
6.69 in. |
| Drag coefficient (Cd) | 0.33 |
|---|
| Minimum turning circle (turning diameter) |
11.21 m
36.78 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (automatic transmission) | 6 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Independent, spring multi-link with stabilizer |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | 195/65 R15; 205/55 R16; 235/65 R17; 235/60 R18 |
| Wheel rims size | 6.0J x 15; 6.5J x 16; 6.5J x 17; 6.5J x 18 |
|---|
|
|---|
