| General information |
|---|
| Brand | Kia |
|---|
| Model | Magentis |
|---|
| Generation | Magentis I |
|---|
| Modification (Engine) | 2.0 (136 Hp) |
|---|
| Start of production | 2000 year |
|---|
| End of production | 2005 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
12.3 l/100 km
19.12 US mpg22.97 UK mpg8.13 km/l |
| Fuel consumption (economy) - extra urban |
6.9 l/100 km
34.09 US mpg40.94 UK mpg14.49 km/l |
| Fuel consumption (economy) - combined |
8.9 l/100 km
26.43 US mpg31.74 UK mpg11.24 km/l |
| CO2 emissions | 210 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 11.5 sec |
|---|
| Acceleration 0 - 62 mph | 11.5 sec |
|---|
| Acceleration 0 - 60 mph | 10.9 sec |
|---|
| Maximum speed |
207 km/h
128.62 mph |
| Emission standard | Euro 3 |
|---|
| Weight-to-power ratio | 10.9 kg/Hp, 92 Hp/tonne |
|---|
| Weight-to-torque ratio | 8.2 kg/Nm, 121.8 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 136 Hp @ 6000 rpm. |
|---|
| Power per litre | 68.1 Hp/l |
|---|
| Torque |
180 Nm @ 4500 rpm.
132.76 lb.-ft. @ 4500 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | G4JP |
|---|
| Engine displacement |
1997 cm3
121.86 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
85 mm
3.35 in. |
| Piston Stroke |
88 mm
3.46 in. |
| Compression ratio | 10 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1478 kg
3258.43 lbs. |
| Max. weight |
1985 kg
4376.18 lbs. |
| Max load |
507 kg
1117.74 lbs. |
| Trunk (boot) space - minimum |
479 l
16.92 cu. ft. |
| Trunk (boot) space - maximum |
810 l
28.6 cu. ft. |
| Fuel tank capacity |
65 l
17.17 US gal | 14.3 UK gal |
| Max. roof load |
100 kg
220.46 lbs. |
| Permitted trailer load with brakes (12%) |
1700 kg
3747.86 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Dimensions |
|---|
| Length |
4730 mm
186.22 in. |
| Width |
1820 mm
71.65 in. |
| Height |
1410 mm
55.51 in. |
| Wheelbase |
2700 mm
106.3 in. |
| Front track |
1540 mm
60.63 in. |
| Rear (Back) track |
1520 mm
59.84 in. |
| Minimum turning circle (turning diameter) |
11.60 m
38.06 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Double wishbone |
|---|
| Rear suspension | Multi-link independent |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Hydraulic Steering |
|---|
| Tires size | 205/60 R15 |
| Wheel rims size | 15 |
|---|
|
|---|
