General information
BrandHyundai
Model IONIQ
Generation IONIQ (facelift 2019)
Modification (Engine) 1.6 GDI (141 Hp) Hybrid DCT
Start of production 2019 year
Powertrain Architecture FHEV (Full Hybrid Electric Vehicle)
Body typeLiftback
Seats 5
Doors 5
Performance specs
Fuel Type Petrol (Gasoline)
Acceleration 0 - 100 km/h10.8 sec
Acceleration 0 - 62 mph10.8 sec
Acceleration 0 - 60 mph 10.3 sec
Maximum speed 185 km/h 114.95 mph
Emission standard Euro 6d-TEMP
Weight-to-power ratio 10.4 kg/Hp, 96 Hp/tonne
Weight-to-torque ratio 5.5 kg/Nm, 180.4 Nm/tonne
Electric cars and hybrids specs
Gross battery capacity 1.56 kWh
Electric motor 1
Electric motor power 44 Hp
Electric motor Torque 170 Nm 125.39 lb.-ft.
System power 141 Hp
System torque 265 Nm 195.45 lb.-ft.
Internal combustion engine specs
Power 105 Hp @ 5700 rpm.
Power per litre 66.5 Hp/l
Torque 147 Nm @ 4000 rpm. 108.42 lb.-ft. @ 4000 rpm.
Engine displacement 1580 cm3 96.42 cu. in.
Number of cylinders 4
Position of cylinders Inline
Cylinder Bore 72 mm 2.83 in.
Piston Stroke 97 mm 3.82 in.
Compression ratio 13
Number of valves per cylinder 4
Valvetrain DOHC
Space, Volume and weights
Kerb Weight 1469 kg 3238.59 lbs.
Max. weight 1870 kg 4122.64 lbs.
Max load 401 kg 884.05 lbs.
Trunk (boot) space - minimum 443 l 15.64 cu. ft.
Trunk (boot) space - maximum 1505 l 53.15 cu. ft.
Fuel tank capacity 45 l 11.89 US gal | 9.9 UK gal
Permitted trailer load with brakes (12%) 750 kg 1653.47 lbs.
Permitted towbar download 75 kg 165.35 lbs.
Dimensions
Length 4470 mm 175.98 in.
Width 1820 mm 71.65 in.
Width including mirrors 2045 mm 80.51 in.
Height 1450 mm 57.09 in.
Wheelbase 2700 mm 106.3 in.
Front track 1549-1563 mm 60.98 - 61.54 in.
Rear (Back) track 1563-1577 mm 61.54 - 62.09 in.
Minimum turning circle (turning diameter) 10.6 m 34.78 ft.
Drivetrain, brakes and suspension specs
Drive wheel Front wheel drive
Number of Gears (automatic transmission) 6 DCT
Front suspension Independent type McPherson
Rear suspension Multi-link independent
Front brakesDisc
Rear brakesDisc
Assisting systemsABS (Anti-lock braking system)
Steering type Steering rack and pinion
Power steering Electric Steering
Tires size 195/65 R15; 225/45 R17
Wheel rims size6J x 15; 7J x 17
