| General information |
|---|
| Brand | Hyundai |
|---|
| Model | i40 |
|---|
| Generation | i40 Sedan (facelift 2015) |
|---|
| Modification (Engine) | 1.6 GDI (135 Hp) |
|---|
| Start of production | 2015 year |
|---|
| End of production | 2018 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
8.3-8.5 l/100 km
28.34 - 27.67 US mpg34.03 - 33.23 UK mpg12.05 - 11.76 km/l |
| Fuel consumption (economy) - extra urban |
5.2-5.5 l/100 km
45.23 - 42.77 US mpg54.32 - 51.36 UK mpg19.23 - 18.18 km/l |
| Fuel consumption (economy) - combined |
6.3-6.6 l/100 km
37.34 - 35.64 US mpg44.84 - 42.8 UK mpg15.87 - 15.15 km/l |
| CO2 emissions | 147-153 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 11.5 sec |
|---|
| Acceleration 0 - 62 mph | 11.5 sec |
|---|
| Acceleration 0 - 60 mph | 10.9 sec |
|---|
| Maximum speed |
197 km/h
122.41 mph |
| Emission standard | Euro 6 |
|---|
| Weight-to-power ratio | 10.4 kg/Hp, 96.3 Hp/tonne |
|---|
| Weight-to-torque ratio | 8.5 kg/Nm, 117 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 135 Hp @ 6300 rpm. |
|---|
| Power per litre | 84.9 Hp/l |
|---|
| Torque |
164 Nm @ 4850 rpm.
120.96 lb.-ft. @ 4850 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
1591 cm3
97.09 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
77 mm
3.03 in. |
| Piston Stroke |
85.44 mm
3.36 in. |
| Compression ratio | 11 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1402 kg
3090.88 lbs. |
| Max. weight |
1980 kg
4365.15 lbs. |
| Max load |
578 kg
1274.27 lbs. |
| Trunk (boot) space - minimum |
506 l
17.87 cu. ft. |
| Trunk (boot) space - maximum |
1672 l
59.05 cu. ft. |
| Fuel tank capacity |
70 l
18.49 US gal | 15.4 UK gal |
| Max. roof load |
100 kg
220.46 lbs. |
| Dimensions |
|---|
| Length |
4775 mm
187.99 in. |
| Width |
1815 mm
71.46 in. |
| Height |
1470 mm
57.87 in. |
| Wheelbase |
2770 mm
109.06 in. |
| Front track |
1591 mm
62.64 in. |
| Rear (Back) track |
1597 mm
62.87 in. |
| Ride height (ground clearance) |
140 mm
5.51 in. |
| Minimum turning circle (turning diameter) |
10.94 m
35.89 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent type McPherson |
|---|
| Rear suspension | Independent, spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 205/60 R16; 215/50 R17; 225/45 R18 |
| Wheel rims size | 7.0J x 16; 7.5J x 17; 8.0J x 18 |
|---|
|
|---|
