| General information |
|---|
| Brand | Ford |
|---|
| Model | S-MAX |
|---|
| Generation | S-MAX II (facelift 2019) |
|---|
| Modification (Engine) | 1.5 EcoBoost (165 Hp) |
|---|
| Start of production | November, 2019 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | MPV |
|---|
| Seats | 5-7 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban (NEDC, WLTP equivalent) |
9.7-10.2 l/100 km
24.25 - 23.06 US mpg29.12 - 27.69 UK mpg10.31 - 9.8 km/l |
| Fuel consumption (economy) - extra urban (NEDC, WLTP equivalent) |
6.1-6.3 l/100 km
38.56 - 37.34 US mpg46.31 - 44.84 UK mpg16.39 - 15.87 km/l |
| Fuel consumption (economy) - combined (NEDC, WLTP equivalent) |
7.4-7.6 l/100 km
31.79 - 30.95 US mpg38.17 - 37.17 UK mpg13.51 - 13.16 km/l |
| CO2 emissions (NEDC, WLTP equivalent) | 170-175 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 10.2 sec |
|---|
| Acceleration 0 - 62 mph | 10.2 sec |
|---|
| Acceleration 0 - 60 mph | 9.7 sec |
|---|
| Maximum speed |
203 km/h
126.14 mph |
| Emission standard | Euro 6d-TEMP-EVAP-ISC |
|---|
| Weight-to-power ratio | 10.4 kg/Hp, 96.5 Hp/tonne |
|---|
| Weight-to-torque ratio | 7.1 kg/Nm, 141.6 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 165 Hp @ 5500-6000 rpm. |
|---|
| Torque |
242 Nm @ 1650-4500 rpm.
178.49 lb.-ft. @ 1650-4500 rpm. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Turbocharger |
|---|
| Engine systems | Start & Stop System |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1709 kg
3767.7 lbs. |
| Max. weight |
2450 kg
5401.33 lbs. |
| Max load |
741 kg
1633.63 lbs. |
| Trunk (boot) space - minimum |
965 l
34.08 cu. ft. |
| Trunk (boot) space - maximum |
2020 l
71.34 cu. ft. |
| Fuel tank capacity |
65 l
17.17 US gal | 14.3 UK gal |
| Max. roof load |
75 kg
165.35 lbs. |
| Permitted trailer load with brakes (8%) |
1800 kg
3968.32 lbs. |
| Permitted trailer load with brakes (12%) |
1600 kg
3527.4 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
90 kg
198.42 lbs. |
| Dimensions |
|---|
| Length |
4796 mm
188.82 in. |
| Width |
1916 mm
75.43 in. |
| Width with mirrors folded |
1953 mm
76.89 in. |
| Width including mirrors |
2137 mm
84.13 in. |
| Height |
1655 mm
65.16 in. |
| Wheelbase |
2850 mm
112.2 in. |
| Minimum turning circle (turning diameter) |
11.95 m
39.21 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Independent, spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 235/55 R17; 235/50 R18 |
| Wheel rims size | 7.5J x 17; 7.5J x 18 |
|---|
|
|---|
