| General information |
|---|
| Brand | Ford |
|---|
| Model | C-MAX |
|---|
| Generation | C-MAX (Facelift 2007) |
|---|
| Modification (Engine) | 1.6 16V (100 Hp) |
|---|
| Start of production | 2007 year |
|---|
| End of production | 2010 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | MPV |
|---|
| Seats | 5 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
8.9 l/100 km
26.43 US mpg31.74 UK mpg11.24 km/l |
| Fuel consumption (economy) - extra urban |
5.7 l/100 km
41.27 US mpg49.56 UK mpg17.54 km/l |
| Fuel consumption (economy) - combined |
6.9 l/100 km
34.09 US mpg40.94 UK mpg14.49 km/l |
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 12.9 sec |
|---|
| Acceleration 0 - 62 mph | 12.9 sec |
|---|
| Acceleration 0 - 60 mph | 12.3 sec |
|---|
| Maximum speed |
175 km/h
108.74 mph |
| Emission standard | Euro 4 |
|---|
| Weight-to-power ratio | 13.4 kg/Hp, 74.4 Hp/tonne |
|---|
| Weight-to-torque ratio | 9.4 kg/Nm, 106.4 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 100 Hp @ 6000 rpm. |
|---|
| Power per litre | 62.7 Hp/l |
|---|
| Torque |
143 Nm @ 4000 rpm.
105.47 lb.-ft. @ 4000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine displacement |
1596 cm3
97.39 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
79 mm
3.11 in. |
| Piston Stroke |
81.4 mm
3.2 in. |
| Compression ratio | 11 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Naturally aspirated engine |
|---|
| Valvetrain | DOHC |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1344 kg
2963.01 lbs. |
| Max. weight |
1855 kg
4089.57 lbs. |
| Max load |
511 kg
1126.56 lbs. |
| Fuel tank capacity |
55 l
14.53 US gal | 12.1 UK gal |
| Dimensions |
|---|
| Length |
4372 mm
172.13 in. |
| Width |
1825 mm
71.85 in. |
| Height |
1595 mm
62.8 in. |
| Wheelbase |
2640 mm
103.94 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Independent, spring multi-link with stabilizer |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
|
|---|
