| General information |
|---|
| Brand | Fiat |
|---|
| Model | Doblo |
|---|
| Generation | Doblo II Long (facelift 2015) |
|---|
| Modification (Engine) | 1.6 (105 Hp) MultiJet |
|---|
| Start of production | 2015 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan |
|---|
| Seats | 7 |
|---|
| Doors | 5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
6.1-6.4 l/100 km
38.56 - 36.75 US mpg46.31 - 44.14 UK mpg16.39 - 15.63 km/l |
| Fuel consumption (economy) - extra urban |
4.7-5.3 l/100 km
50.05 - 44.38 US mpg60.1 - 53.3 UK mpg21.28 - 18.87 km/l |
| Fuel consumption (economy) - combined |
5.2-5.7 l/100 km
45.23 - 41.27 US mpg54.32 - 49.56 UK mpg19.23 - 17.54 km/l |
| CO2 emissions | 138 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 13.4 sec |
|---|
| Acceleration 0 - 62 mph | 13.4 sec |
|---|
| Acceleration 0 - 60 mph | 12.7 sec |
|---|
| Maximum speed |
164 km/h
101.9 mph |
| Emission standard | Euro 5 |
|---|
| Weight-to-power ratio | 14.5 kg/Hp, 68.9 Hp/tonne |
|---|
| Weight-to-torque ratio | 5.3 kg/Nm, 190.2 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 105 Hp @ 4000 rpm. |
|---|
| Power per litre | 65.7 Hp/l |
|---|
| Torque |
290 Nm @ 1500 rpm.
213.89 lb.-ft. @ 1500 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | 198A3000, 263A7000 |
|---|
| Engine displacement |
1598 cm3
97.52 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
79.5 mm
3.13 in. |
| Piston Stroke |
80.5 mm
3.17 in. |
| Compression ratio | 16.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Engine oil capacity |
4.9 l
5.18 US qt | 4.31 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
6.7 l
7.08 US qt | 5.9 UK qt |
| Engine systems | Particulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1525 kg
3362.05 lbs. |
| Trunk (boot) space - minimum |
1050 l
37.08 cu. ft. |
| Trunk (boot) space - maximum |
4000 l
141.26 cu. ft. |
| Fuel tank capacity |
60 l
15.85 US gal | 13.2 UK gal |
| Permitted trailer load with brakes (12%) |
1000 kg
2204.62 lbs. |
| Permitted trailer load without brakes |
500 kg
1102.31 lbs. |
| Dimensions |
|---|
| Length |
4756 mm
187.24 in. |
| Width |
1832 mm
72.13 in. |
| Height |
1895/2115 mm
74.61 in. |
| Wheelbase |
3105 mm
122.24 in. |
| Front track |
1510 mm
59.45 in. |
| Rear (Back) track |
1530 mm
60.24 in. |
| Minimum turning circle (turning diameter) |
12.5 m
41.01 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent type McPherson |
|---|
| Rear suspension | Independent, spring |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Drum |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 195/60 R16 C 99T |
| Wheel rims size | 16 |
|---|
|
|---|
