| General information |
|---|
| Brand | Citroen |
|---|
| Model | SpaceTourer |
|---|
| Generation | SpaceTourer XL |
|---|
| Modification (Engine) | 1.5 BlueHDi (120 Hp) |
|---|
| Start of production | June, 2018 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Minivan, MPV |
|---|
| Seats | 8-9 |
|---|
| Doors | 4-5 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban (NEDC) |
5.2-5.3 l/100 km
45.23 - 44.38 US mpg54.32 - 53.3 UK mpg19.23 - 18.87 km/l |
| Fuel consumption (economy) - extra urban (NEDC) |
4.6-4.7 l/100 km
51.13 - 50.05 US mpg61.41 - 60.1 UK mpg21.74 - 21.28 km/l |
| Fuel consumption (economy) - combined (NEDC) |
4.8-4.9 l/100 km
49 - 48 US mpg58.85 - 57.65 UK mpg20.83 - 20.41 km/l |
| CO2 emissions (NEDC) | 127-130 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 12 sec |
|---|
| Acceleration 0 - 62 mph | 12 sec |
|---|
| Acceleration 0 - 60 mph | 11.4 sec |
|---|
| Maximum speed |
160 km/h
99.42 mph |
| Emission standard | Euro 6d-TEMP |
|---|
| Weight-to-power ratio | 13.8 kg/Hp, 72.3 Hp/tonne |
|---|
| Weight-to-torque ratio | 5.5 kg/Nm, 180.7 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 120 Hp @ 3500 rpm. |
|---|
| Power per litre | 80.1 Hp/l |
|---|
| Torque |
300 Nm @ 1750 rpm.
221.27 lb.-ft. @ 1750 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | YHV DV5RUC |
|---|
| Engine displacement |
1499 cm3
91.47 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Engine oil capacity |
5.75 l
6.08 US qt | 5.06 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Engine systems | Start & Stop SystemParticulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1660 kg
3659.67 lbs. |
| Max. weight |
2785 kg
6139.87 lbs. |
| Max load |
1125 kg
2480.2 lbs. |
| Trunk (boot) space - minimum |
1237 l
43.68 cu. ft. |
| Trunk (boot) space - maximum |
4554 l
160.82 cu. ft. |
| Fuel tank capacity |
69 l
18.23 US gal | 15.18 UK gal |
| AdBlue tank |
22.4 l
5.92 US gal | 4.93 UK gal |
| Max. roof load |
150 kg
330.69 lbs. |
| Permitted trailer load with brakes (12%) |
1800 kg
3968.32 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
72 kg
158.73 lbs. |
| Dimensions |
|---|
| Length |
5306 mm
208.9 in. |
| Width |
1920 mm
75.59 in. |
| Width including mirrors |
2204 mm
86.77 in. |
| Height |
1890 mm
74.41 in. |
| Wheelbase |
3275 mm
128.94 in. |
| Front track |
1627 mm
64.06 in. |
| Rear (Back) track |
1600 mm
62.99 in. |
| Front overhang |
878 mm
34.57 in. |
| Rear overhang |
1153 mm
45.39 in. |
| Minimum turning circle (turning diameter) |
12.4 m
40.68 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent type McPherson |
|---|
| Rear suspension | Wishbone |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 215/65 R16; 225/55 R17 |
| Wheel rims size | 16; 17 |
|---|
|
|---|
