General information |
Brand | Citroen |
Model | CX |
Generation | CX I (Phase I, 1982) |
Modification (Engine) | 20 (106 Hp) |
Start of production | 1982 year |
End of production | 1985 year |
Powertrain Architecture | Internal Combustion engine |
Body type | Hatchback |
Seats | 5 |
Doors | 5 |
Performance specs |
---|
Fuel Type | Petrol (Gasoline) |
Acceleration 0 - 100 km/h | 11.7 sec |
Acceleration 0 - 62 mph | 11.7 sec |
Acceleration 0 - 60 mph | 11.1 sec |
Maximum speed |
176 km/h
109.36 mph |
Weight-to-power ratio | 11.7 kg/Hp, 85.8 Hp/tonne |
Weight-to-torque ratio | 7.4 kg/Nm, 134.4 Nm/tonne |
Engine specs |
---|
Power | 106 Hp @ 5500 rpm. |
Power per litre | 53.1 Hp/l |
Torque |
166 Nm @ 3250 rpm.
122.44 lb.-ft. @ 3250 rpm. |
Engine location | Front, Transverse |
Engine Model/Code | 829.A5 |
Engine displacement |
1995 cm3
121.74 cu. in. |
Number of cylinders | 4 |
Position of cylinders | Inline |
Cylinder Bore |
88 mm
3.46 in. |
Piston Stroke |
82 mm
3.23 in. |
Compression ratio | 9.2 |
Number of valves per cylinder | 2 |
Fuel System | Carburettor |
Engine aspiration | Naturally aspirated engine |
Engine oil capacity |
5.5 l
5.81 US qt | 4.84 UK qt |
Oil viscosity | No Data |
Engine oil specification |
Coolant |
9.5-12.0 l
10.04 - 12.68 US qt | 8.36 - 10.56 UK qt |
|
---|
Space, Volume and weights |
---|
Kerb Weight |
1235 kg
2722.71 lbs. |
Max. weight |
1780 kg
3924.23 lbs. |
Max load |
545 kg
1201.52 lbs. |
Trunk (boot) space - minimum |
325 l
11.48 cu. ft. |
Fuel tank capacity |
68 l
17.96 US gal | 14.96 UK gal |
Dimensions |
---|
Length |
4659 mm
183.43 in. |
Width |
1770 mm
69.69 in. |
Height |
1360 mm
53.54 in. |
Wheelbase |
2845 mm
112.01 in. |
Front track |
1514 mm
59.61 in. |
Rear (Back) track |
1360 mm
53.54 in. |
Front overhang |
1050 mm
41.34 in. |
Rear overhang |
764 mm
30.08 in. |
Drag coefficient (Cd) | 0.36 |
Minimum turning circle (turning diameter) |
11.7 m
38.39 ft. |
Drivetrain, brakes and suspension specs |
---|
Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
Drive wheel | Front wheel drive |
Number of Gears (manual transmission) | 5 |
Front brakes | Ventilated discs |
Rear brakes | Disc |
Steering type | Steering rack and pinion |
|
