| General information |
|---|
| Brand | BMW |
|---|
| Model | 5 Series |
|---|
| Generation | 5 Series Sedan (F10) |
|---|
| Modification (Engine) | 520d (184 Hp) |
|---|
| Start of production | 2010 year |
|---|
| End of production | 2013 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
5.9 l/100 km
39.87 US mpg47.88 UK mpg16.95 km/l |
| Fuel consumption (economy) - extra urban |
4.3 l/100 km
54.7 US mpg65.69 UK mpg23.26 km/l |
| Fuel consumption (economy) - combined |
4.9 l/100 km
48 US mpg57.65 UK mpg20.41 km/l |
| CO2 emissions | 129 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 8.1 sec |
|---|
| Acceleration 0 - 62 mph | 8.1 sec |
|---|
| Acceleration 0 - 60 mph | 7.7 sec |
|---|
| Maximum speed |
227 km/h
141.05 mph |
| Emission standard | Euro 5 |
|---|
| Weight-to-power ratio | 8.8 kg/Hp, 113.6 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.3 kg/Nm, 234.6 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 184 Hp @ 4000 rpm. |
|---|
| Power per litre | 92.2 Hp/l |
|---|
| Torque |
380 Nm @ 1750-2750 rpm.
280.27 lb.-ft. @ 1750-2750 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | N47D20C |
|---|
| Engine displacement |
1995 cm3
121.74 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
84 mm
3.31 in. |
| Piston Stroke |
90 mm
3.54 in. |
| Compression ratio | 16.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Engine oil capacity |
5.2 l
5.49 US qt | 4.58 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
7.2-7.5 l
7.61 - 7.93 US qt | 6.34 - 6.6 UK qt |
| Engine systems | Particulate filter |
|---|
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1620 kg
3571.49 lbs. |
| Max. weight |
2230 kg
4916.31 lbs. |
| Max load |
610 kg
1344.82 lbs. |
| Trunk (boot) space - minimum |
520 l
18.36 cu. ft. |
| Fuel tank capacity |
70 l
18.49 US gal | 15.4 UK gal |
| Max. roof load |
100 kg
220.46 lbs. |
| Permitted trailer load with brakes (12%) |
2000 kg
4409.25 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
90 kg
198.42 lbs. |
| Dimensions |
|---|
| Length |
4899 mm
192.87 in. |
| Width |
1860 mm
73.23 in. |
| Height |
1464 mm
57.64 in. |
| Wheelbase |
2968 mm
116.85 in. |
| Front track |
1600 mm
62.99 in. |
| Rear (Back) track |
1627 mm
64.06 in. |
| Ride height (ground clearance) |
141 mm
5.55 in. |
| Drag coefficient (Cd) | 0.28 |
|---|
| Minimum turning circle (turning diameter) |
11.95 m
39.21 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Double wishbone |
|---|
| Rear suspension | Multi-link independent |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 225/55 R17 97W |
| Wheel rims size | 8J x 17 |
|---|
|
|---|
