| General information |
|---|
| Brand | BMW |
|---|
| Model | 5 Series |
|---|
| Generation | 5 Series Active Hybrid (F10H LCI, facelift 2013) |
|---|
| Modification (Engine) | ActiveHybrid 3.0 (340 Hp) |
|---|
| Start of production | 2013 year |
|---|
| End of production | 2016 year |
|---|
| Powertrain Architecture | FHEV (Full Hybrid Electric Vehicle) |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
6.1-6.7 l/100 km
38.56 - 35.11 US mpg46.31 - 42.16 UK mpg16.39 - 14.93 km/l |
| Fuel consumption (economy) - extra urban |
6.6-7.2 l/100 km
35.64 - 32.67 US mpg42.8 - 39.23 UK mpg15.15 - 13.89 km/l |
| Fuel consumption (economy) - combined |
6.4-7.0 l/100 km
36.75 - 33.6 US mpg44.14 - 40.35 UK mpg15.63 - 14.29 km/l |
| CO2 emissions | 149-163 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 5.9 sec |
|---|
| Acceleration 0 - 62 mph | 5.9 sec |
|---|
| Acceleration 0 - 60 mph | 5.6 sec |
|---|
| Maximum speed |
250 km/h
155.34 mph |
| Emission standard | Euro 6 |
|---|
| Weight-to-power ratio | 5.4 kg/Hp, 183.8 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.6 kg/Nm, 216.2 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 340 Hp @ 5800-6400 rpm. |
|---|
| Power per litre | 114.1 Hp/l |
|---|
| Torque |
400 Nm @ 1200-5000 rpm.
295.02 lb.-ft. @ 1200-5000 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | N55B30A |
|---|
| Engine displacement |
2979 cm3
181.79 cu. in. |
| Number of cylinders | 6 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
84 mm
3.31 in. |
| Piston Stroke |
89.6 mm
3.53 in. |
| Compression ratio | 10.2 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Direct injection |
|---|
| Engine aspiration | Twin-power turbo, Intercooler |
|---|
| Engine oil capacity |
6.5 l
6.87 US qt | 5.72 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
9-9.3 l
9.51 - 9.83 US qt | 7.92 - 8.18 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1850 kg
4078.55 lbs. |
| Max. weight |
2400 kg
5291.09 lbs. |
| Max load |
550 kg
1212.54 lbs. |
| Trunk (boot) space - minimum |
375 l
13.24 cu. ft. |
| Fuel tank capacity |
67 l
17.7 US gal | 14.74 UK gal |
| Max. roof load |
100 kg
220.46 lbs. |
| Dimensions |
|---|
| Length |
4907 mm
193.19 in. |
| Width |
1860 mm
73.23 in. |
| Height |
1464 mm
57.64 in. |
| Wheelbase |
2968 mm
116.85 in. |
| Front track |
1600 mm
62.99 in. |
| Rear (Back) track |
1627 mm
64.06 in. |
| Ride height (ground clearance) |
141 mm
5.55 in. |
| Drag coefficient (Cd) | 0.27 |
|---|
| Minimum turning circle (turning diameter) |
12.0 m
39.37 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) and electric motor drive the rear wheels of the car with the ability to work in full electric or mixed mode. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of Gears (automatic transmission) | 8 Steptronic |
|---|
| Front suspension | Double wishbone |
|---|
| Rear suspension | Multi-link independent |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Ventilated discs |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 225/55 R17; 245/45 R18; 275/40 R18; 245/40 R19; 275/35 R19; 245/35 R20; 275/30 R20 |
| Wheel rims size | 8J x 17; 8J x 18; 9J x 18; 8.5J x 19; 9J x 19; 8.5J x 20; 9J x 20 |
|---|
|
|---|
