| General information |
|---|
| Brand | BMW |
|---|
| Model | 3 Series |
|---|
| Generation | 3 Series Sedan (E90) |
|---|
| Modification (Engine) | 318d (122 Hp) |
|---|
| Start of production | 2006 year |
|---|
| End of production | 2007 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
7.6 l/100 km
30.95 US mpg37.17 UK mpg13.16 km/l |
| Fuel consumption (economy) - extra urban |
4.4 l/100 km
53.46 US mpg64.2 UK mpg22.73 km/l |
| Fuel consumption (economy) - combined |
5.7 l/100 km
41.27 US mpg49.56 UK mpg17.54 km/l |
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 10.6 sec |
|---|
| Acceleration 0 - 62 mph | 10.6 sec |
|---|
| Acceleration 0 - 60 mph | 10.1 sec |
|---|
| Maximum speed |
206 km/h
128 mph |
| Weight-to-power ratio | 11.8 kg/Hp, 85 Hp/tonne |
|---|
| Weight-to-torque ratio | 5.1 kg/Nm, 195.1 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 122 Hp @ 4000 rpm. |
|---|
| Power per litre | 61.2 Hp/l |
|---|
| Torque |
280 Nm @ 1750 rpm.
206.52 lb.-ft. @ 1750 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | M47D20TU2 |
|---|
| Engine displacement |
1995 cm3
121.74 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
84 mm
3.31 in. |
| Piston Stroke |
90 mm
3.54 in. |
| Compression ratio | 17 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Diesel Commonrail |
|---|
| Engine aspiration | Turbocharger |
|---|
| Engine oil capacity |
5.2 l
5.49 US qt | 4.58 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
7.8 l
8.24 US qt | 6.86 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1435 kg
3163.63 lbs. |
| Max. weight |
1950 kg
4299.01 lbs. |
| Max load |
515 kg
1135.38 lbs. |
| Trunk (boot) space - maximum |
460 l
16.24 cu. ft. |
| Fuel tank capacity |
61 l
16.11 US gal | 13.42 UK gal |
| Dimensions |
|---|
| Length |
4520 mm
177.95 in. |
| Width |
1817 mm
71.54 in. |
| Height |
1421 mm
55.94 in. |
| Wheelbase |
2760 mm
108.66 in. |
| Front track |
1500 mm
59.06 in. |
| Rear (Back) track |
1513 mm
59.57 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the rear wheels of the vehicle. |
|---|
| Drive wheel | Rear wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent, Spring McPherson, with stabilizer |
|---|
| Rear suspension | Helical spring |
|---|
| Front brakes | Disc |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Tires size | 205/55 R16 |
| Wheel rims size | 16 |
|---|
|
|---|
