| General information |
|---|
| Brand | Audi |
|---|
| Model | A6 |
|---|
| Generation | A6 (4F,C6) |
|---|
| Modification (Engine) | 2.0 TDI (140 Hp) |
|---|
| Start of production | July, 2004 year |
|---|
| End of production | October, 2008 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Sedan |
|---|
| Seats | 5 |
|---|
| Doors | 4 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban |
8 l/100 km
29.4 US mpg35.31 UK mpg12.5 km/l |
| Fuel consumption (economy) - extra urban |
4.8 l/100 km
49 US mpg58.85 UK mpg20.83 km/l |
| Fuel consumption (economy) - combined |
6 l/100 km
39.2 US mpg47.08 UK mpg16.67 km/l |
| CO2 emissions | 161 g/km |
|---|
| Fuel Type | Diesel |
|---|
| Acceleration 0 - 100 km/h | 10.3 sec |
|---|
| Acceleration 0 - 62 mph | 10.3 sec |
|---|
| Acceleration 0 - 60 mph | 9.8 sec |
|---|
| Maximum speed |
210 km/h
130.49 mph |
| Emission standard | Euro 4 |
|---|
| Weight-to-power ratio | 11 kg/Hp, 90.9 Hp/tonne |
|---|
| Weight-to-torque ratio | 4.8 kg/Nm, 207.8 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 140 Hp @ 4000 rpm. |
|---|
| Power per litre | 71.1 Hp/l |
|---|
| Torque |
320 Nm @ 1750-2500 rpm.
236.02 lb.-ft. @ 1750-2500 rpm. |
| Engine location | Front, Longitudinal |
|---|
| Engine Model/Code | BLB, BRE |
|---|
| Engine displacement |
1968 cm3
120.09 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
81 mm
3.19 in. |
| Piston Stroke |
95.5 mm
3.76 in. |
| Compression ratio | 19.5 |
|---|
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Pump-nozzle (Unit Injector) |
|---|
| Engine aspiration | Turbocharger, Intercooler |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
3.8 l
4.02 US qt | 3.34 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
8.0 l
8.45 US qt | 7.04 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1540 kg
3395.12 lbs. |
| Max. weight |
2120 kg
4673.8 lbs. |
| Max load |
580 kg
1278.68 lbs. |
| Trunk (boot) space - maximum |
546 l
19.28 cu. ft. |
| Fuel tank capacity |
70 l
18.49 US gal | 15.4 UK gal |
| Max. roof load |
100 kg
220.46 lbs. |
| Permitted trailer load with brakes (8%) |
1800 kg
3968.32 lbs. |
| Permitted trailer load with brakes (12%) |
1600 kg
3527.4 lbs. |
| Permitted trailer load without brakes |
750 kg
1653.47 lbs. |
| Permitted towbar download |
85 kg
187.39 lbs. |
| Dimensions |
|---|
| Length |
4916 mm
193.54 in. |
| Width |
1855 mm
73.03 in. |
| Height |
1459 mm
57.44 in. |
| Wheelbase |
2843 mm
111.93 in. |
| Front track |
1612 mm
63.46 in. |
| Rear (Back) track |
1618 mm
63.7 in. |
| Drag coefficient (Cd) | 0.29 |
|---|
| Minimum turning circle (turning diameter) |
11.9 m
39.04 ft. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 6 |
|---|
| Front suspension | Independent multi-link |
|---|
| Rear suspension | Independent on trapezoidal lever |
|---|
| Front brakes | Ventilated discs |
|---|
| Rear brakes | Disc |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Tires size | 205/60 R16 |
| Wheel rims size | 7J x 16 |
|---|
|
|---|
