| General information |
|---|
| Brand | Abarth |
|---|
| Model | 500 |
|---|
| Generation | 500C |
|---|
| Modification (Engine) | 1.4 T-Jet (135 Hp) |
|---|
| Start of production | 2012 year |
|---|
| End of production | 2014 year |
|---|
| Powertrain Architecture | Internal Combustion engine |
|---|
| Body type | Cabriolet |
|---|
| Seats | 4 |
|---|
| Doors | 2 |
|---|
| Performance specs |
|---|
| Fuel consumption (economy) - urban (NEDC) |
8.5 l/100 km
27.67 US mpg33.23 UK mpg11.76 km/l |
| Fuel consumption (economy) - extra urban (NEDC) |
5.4 l/100 km
43.56 US mpg52.31 UK mpg18.52 km/l |
| Fuel consumption (economy) - combined (NEDC) |
6.5 l/100 km
36.19 US mpg43.46 UK mpg15.38 km/l |
| CO2 emissions (NEDC) | 155 g/km |
|---|
| Fuel Type | Petrol (Gasoline) |
|---|
| Acceleration 0 - 100 km/h | 7.9 sec |
|---|
| Acceleration 0 - 62 mph | 7.9 sec |
|---|
| Acceleration 0 - 60 mph | 7.5 sec |
|---|
| Maximum speed |
205 km/h
127.38 mph |
| Emission standard | Euro 5 |
|---|
| Weight-to-power ratio | 8 kg/Hp, 125.6 Hp/tonne |
|---|
| Weight-to-torque ratio | 5.2 kg/Nm, 191.6 Nm/tonne |
|---|
| Engine specs |
|---|
| Power | 135 Hp @ 5500 rpm. |
|---|
| Power per litre | 98.7 Hp/l |
|---|
| Torque |
206 Nm @ 3000 rpm.
151.94 lb.-ft. @ 3000 rpm. |
| Engine location | Front, Transverse |
|---|
| Engine Model/Code | 312A1000 |
|---|
| Engine displacement |
1368 cm3
83.48 cu. in. |
| Number of cylinders | 4 |
|---|
| Position of cylinders | Inline |
|---|
| Cylinder Bore |
72 mm
2.83 in. |
| Piston Stroke |
84 mm
3.31 in. |
| Number of valves per cylinder | 4 |
|---|
| Fuel System | Multi-point indirect injection |
|---|
| Engine aspiration | Turbocharger |
|---|
| Valvetrain | DOHC |
|---|
| Engine oil capacity |
2.9 l
3.06 US qt | 2.55 UK qt |
| Oil viscosity | No Data |
| Engine oil specification |
| Coolant |
5.2 l
5.49 US qt | 4.58 UK qt |
|
|---|
| Space, Volume and weights |
|---|
| Kerb Weight |
1075 kg
2369.97 lbs. |
| Max. weight |
1430 kg
3152.61 lbs. |
| Max load |
355 kg
782.64 lbs. |
| Trunk (boot) space - minimum |
182 l
6.43 cu. ft. |
| Trunk (boot) space - maximum |
520 l
18.36 cu. ft. |
| Fuel tank capacity |
35 l
9.25 US gal | 7.7 UK gal |
| Dimensions |
|---|
| Length |
3657 mm
143.98 in. |
| Width |
1627 mm
64.06 in. |
| Width including mirrors |
1893 mm
74.53 in. |
| Height |
1488 mm
58.58 in. |
| Wheelbase |
2300 mm
90.55 in. |
| Front track |
1409 mm
55.47 in. |
| Rear (Back) track |
1402 mm
55.2 in. |
| Front overhang |
776 mm
30.55 in. |
| Rear overhang |
581 mm
22.87 in. |
| Drivetrain, brakes and suspension specs |
|---|
| Drivetrain Architecture | The Internal combustion engine (ICE) drives the front wheels of the vehicle. |
|---|
| Drive wheel | Front wheel drive |
|---|
| Number of Gears (manual transmission) | 5 |
|---|
| Front suspension | Independent type McPherson, Transverse stabilizer |
|---|
| Rear suspension | Transverse stabilizer, Elastic beam |
|---|
| Front brakes | Ventilated discs, 284x22 mm |
|---|
| Rear brakes | Disc, 240x11 mm |
|---|
| Assisting systems | ABS (Anti-lock braking system) |
|---|
| Steering type | Steering rack and pinion |
|---|
| Power steering | Electric Steering |
|---|
| Tires size | 195/45 R16 |
| Wheel rims size | 6.5J x 16 |
|---|
|
|---|
